Product Features

Rapid-Exchange Design

Facilitates efficient device exchange and streamlined procedural handling.

Highly Lubricious Hydrophilic Coating

Reduces surface friction and enhances trackability through challenging vascular anatomy.

Rapid Inflation and Deflation

Short inflation and deflation times support efficient procedural workflows.

Low Crossing Profile

The compact folded profile facilitates advancement to distal target lesions.

Extensive Balloon Size Range

A broad range of balloon sizes is available, with balloon lengths of up to 300 mm to accommodate diverse clinical needs.

Product Specifications

Peripheral Balloon Dilatation Catheter Specifications
Code↕Balloon Diameter (mm)↕Balloon Length (mm)↕Catheter Length (cm)↕NP (atm)↕RBP  (atm)↕
K30- 12015S1.2515800616
K30- 12020S1.2520800616
K30- 12030S1.2530800616
K30- 12040S1.2540800616
K30- 12060S1.2560800616
K30- 12080S1.2580800616
K30- 12100S1.25100800616
K30- 12120S1.25120800616
K30- 12150S1.25150800615
K30- 12200S1.25200800615
K30- 15015S1.515800616
K30- 15020S1.520800616
K30- 15030S1.530800616
K30- 15040S1.540800616
K30- 15060S1.560800616
K30- 15080S1.580800616
K30- 15100S1.5100800616
K30- 15120S1.5120800616
K30- 15150S1.5150800615
K30- 15200S1.5200800615
K30-20015S215800616
K30-20020S220800616
K30-20030S230800616
K30-20040S240800616
K30-20060S260800615
K30-20080S280800615
K30-20100S2100800615
K30-20120S2120800615
K30-20150S2150800615
K30-20200S2200800615
K30-20250S2250800615
K30-20300S2300800615
K30-25015S2.515800616
K30-25020S2.520800616
K30-25030S2.530800616
K30-25040S2.540800616
K30-25060S2.560800615
K30-25080S2.580800615
K30-25100S2.5100800615
K30-25120S2.5120800615
K30-25150S2.5150800615
K30-25200S2.5200800615
K30-25250S2.5250800615
K30-25300S2.5300800615
K30-30015S315800616
K30-30020S320800616
K30-30030S330800616
K30-30040S340800616
K30-30060S360800615
K30-30080S380800615
K30-30100S3100800615
K30-30120S3120800615
K30-30150S3150800615
K30-30200S3200800615
K30-30250S3250800615
K30-30300S3300800615
K30-35015S3.515800616
K30-35020S3.520800616
K30-35030S3.530800616
K30-35040S3.540800616
K30-35060S3.560800615
K30-35080S3.580800615
K30-35100S3.5100800615
K30-35120S3.5120800615
K30-35150S3.5150800615
K30-35200S3.5200800615
K30-35250S3.5250800615
K30-35300S3.5300800615
K30-40015S415800616
K30-40020S420800616
K30-40030S430800616
K30-40040S440800616
K30-40060S460800615
K30-40080S480800615
K30-40100S4100800615
K30-40120S4120800615
K30-40150S4150800615
K30-40200S4200800615
K30-40250S4250800615
K30-40300S4300800615
K30-50015S515800614
K30-50020S520800614
K30-50030S530800614
K30-50040S540800614
K30-50060S560800614
K30-50080S580800613
K30-50100S5100800613
K30-50120S5120800613
K30-50150S5150800613
K30-50200S5200800613
K30-50250S5250800613
K30-50300S5300800613
K30-60030S630800614
K30-60040S640800614
K30-60060S660800614
K30-70030S730800612
K30-70040S740800612
K30-70060S760800612
K30- 12015M1.25151500616
K30- 12020M1.25201500616
K30- 12030M1.25301500616
K30- 12040M1.25401500616
K30- 12060M1.25601500616
K30- 12080M1.25801500616
K30- 12100M1.251001500616
K30- 12120M1.251201500616
K30- 12150M1.251501500615
K30- 12200M1.252001500615
K30- 15015M1.5151500616
K30- 15020M1.5201500616
K30- 15030M1.5301500616
K30- 15040M1.5401500616
K30- 15060M1.5601500616
K30- 15080M1.5801500616
K30- 15100M1.51001500616
K30- 15120M1.51201500616
K30- 15150M1.51501500615
K30- 15200M1.52001500615
K30-20015M2151500616
K30-20020M2201500616
K30-20030M2301500616
K30-20040M2401500616
K30-20060M2601500615
K30-20080M2801500615
K30-20100M21001500615
K30-20120M21201500615
K30-20150M21501500615
K30-20200M22001500615
K30-20250M22501500615
K30-20300M23001500615
K30-25015M2.5151500616
K30-25020M2.5201500616
K30-25030M2.5301500616
K30-25040M2.5401500616
K30-25060M2.5601500615
K30-25080M2.5801500615
K30-25100M2.51001500615
K30-25120M2.51201500615
K30-25150M2.51501500615
K30-25200M2.52001500615
K30-25250M2.52501500615
K30-25300M2.53001500615
K30-30015M3151500616
K30-30020M3201500616
K30-30030M3301500616
K30-30040M3401500616
K30-30060M3601500615
K30-30080M3801500615
K30-30100M31001500615
K30-30120M31201500615
K30-30150M31501500615
K30-30200M32001500615
K30-30250M32501500615
K30-30300M33001500615
K30-35015M3.5151500616
K30-35020M3.5201500616
K30-35030M3.5301500616
K30-35040M3.5401500616
K30-35060M3.5601500615
K30-35080M3.5801500615
K30-35100M3.51001500615
K30-35120M3.51201500615
K30-35150M3.51501500615
K30-35200M3.52001500615
K30-35250M3.52501500615
K30-35300M3.53001500615
K30-40015M4151500616
K30-40020M4201500616
K30-40030M4301500616
K30-40040M4401500616
K30-40060M4601500615
K30-40080M4801500615
K30-40100M41001500615
K30-40120M41201500615
K30-40150M41501500615
K30-40200M42001500615
K30-40250M42501500615
K30-40300M43001500615
K30-50015M5151500614
K30-50020M5201500614
K30-50030M5301500614
K30-50040M5401500614
K30-50060M5601500614
K30-50080M5801500613
K30-50100M51001500613
K30-50120M51201500613
K30-50150M51501500613
K30-50200M52001500613
K30-50250M52501500613
K30-50300M53001500613
K30-60030M6301500614
K30-60040M6401500614
K30-60060M6601500614
K30-70030M7301500612
K30-70040M7401500612
K30-70060M7601500612
K30- 12015L1.25152000616
K30- 12020L1.25202000616
K30- 12030L1.25302000616
K30- 12040L1.25402000616
K30- 12060L1.25602000616
K30- 12080L1.25802000616
K30- 12100L1.251002000616
K30- 12120L1.251202000616
K30- 12150L1.251502000615
K30- 12200L1.252002000615
K30- 15015L1.5152000616
K30- 15020L1.5202000616
K30- 15030L1.5302000616
K30- 15040L1.5402000616
K30- 15060L1.5602000616
K30- 15080L1.5802000616
K30- 15100L1.51002000616
K30- 15120L1.51202000616
K30- 15150L1.51502000615
K30- 15200L1.52002000615
K30-20015L2152000616
K30-20020L2202000616
K30-20030L2302000616
K30-20040L2402000616
K30-20060L2602000615
K30-20080L2802000615
K30-20100L21002000615
K30-20120L21202000615
K30-20150L21502000615
K30-20200L22002000615
K30-20250L22502000615
K30-20300L23002000615
K30-25015L2.5152000616
K30-25020L2.5202000616
K30-25030L2.5302000616
K30-25040L2.5402000616
K30-25060L2.5602000615
K30-25080L2.5802000615
K30-25100L2.51002000615
K30-25120L2.51202000615
K30-25150L2.51502000615
K30-25200L2.52002000615
K30-25250L2.52502000615
K30-25300L2.53002000615
K30-30015L3152000616
K30-30020L3202000616
K30-30030L3302000616
K30-30040L3402000616
K30-30060L3602000615
K30-30080L3802000615
K30-30100L31002000615
K30-30120L31202000615
K30-30150L31502000615
K30-30200L32002000615
K30-30250L32502000615
K30-30300L33002000615
K30-35015L3.5152000616
K30-35020L3.5202000616
K30-35030L3.5302000616
K30-35040L3.5402000616
K30-35060L3.5602000615
K30-35080L3.5802000615
K30-35100L3.51002000615
K30-35120L3.51202000615
K30-35150L3.51502000615
K30-35200L3.52002000615
K30-35250L3.52502000615
K30-35300L3.53002000615
K30-40015L4152000616
K30-40020L4202000616
K30-40030L4302000616
K30-40040L4402000616
K30-40060L4602000615
K30-40080L4802000615
K30-40100L41002000615
K30-40120L41202000615
K30-40150L41502000615
K30-40200L42002000615
K30-40250L42502000615
K30-40300L43002000615
K30-50015L5152000614
K30-50020L5202000614
K30-50030L5302000614
K30-50040L5402000614
K30-50060L5602000614
K30-50080L5802000613
K30-50100L51002000613
K30-50120L51202000613
K30-50150L51502000613
K30-50200L52002000613
K30-50250L52502000613
K30-50300L53002000613
K30-60030L6302000614
K30-60040L6402000614
K30-60060L6602000614
K30-70030L7302000612
K30-70040L7402000612
K30-70060L7602000612
